HRC 55° R5*10*20*10*75 2 Flutes Ball Nose End Mill For Aluminum Without Coating

HRC 55° R5*10*20*10*75 2 Flutes Ball Nose End Mill For Aluminum Without Coating
HRC 55° R5*10*20*10*75 2 Flutes Ball Nose End Mill For Aluminum Without Coating
video play

Large Image :  HRC 55° R5*10*20*10*75 2 Flutes Ball Nose End Mill For Aluminum Without Coating

Product Details:
Place of Origin: China
Brand Name: BABOS
Model Number: R5*10*20*10*75 2T
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: Negotiable
Packaging Details: Plastic Box
Delivery Time: 3 days for standard products, 1-2weeks for custom products.
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability: 20,000PCS per month
Contact Now
Detailed Product Description
Cut Diameter: 10mm Cut Length: 20mm
Shank Diameter: 10mm Overall Length: 75mm
Flute Number: 2 Helix Angle: 30°
Tolerance: 0.020mm~0.050mm Customize: Available
Highlight:

HRC 55° Ball Nose End Mill

,

2 Flutes Ball Nose End Mill

,

AITiSiN Coating Ball Nose End Mill

HRC 55° R5*10*0*10*75 2 Flutes Ball Nose End Mill For Aluminum Without Coating

Product Description:

HRC 55° R5*10*0*10*75 2 Flutes Ball Nose End Mill For Aluminum is engineered for high efficiency and precision, making it an excellent choice for professionals in aerospace, mold-making, and precision machining industries.



Features:

  • Product Name: 2 Flutes Ball Nose End Mill For Aluminum
  • Cut Diameter: 10mm
  • Cut Length: 20mm
  • Shank Diameter: 10mm
  • Overall Length: 75mm
  • Coating/Finish Type: /
  • Machine Type: Finish Machining, Roughing Machining

2 Flutes Ball Nose End Mill Specifications
(For Alunminum)
Sizes Cut Diameter
D		 Cut Length
Lc		 Shank Diameter
d		 Overall Length
L		 Flutes No.
R1.5*6*3*50 3 6 3 50 2
R1.5*6*3*75 3 6 3 75 2
R1.5*6*3*100 3 6 3 100 2
R0.5*2*4*50 1 2 4 50 2
R0.75*3*4*50 1.5 3 4 50 2
R1*4*4*50 2 4 4 50 2
R1.25*5*4*50 2.5 5 4 50 2
R1.5*6*4*50 3 6 4 50 2
R1.75*7*4*50 3.5 7 4 50 2
R2*8*4*50 4 8 4 50 2
R2*8*4*75 4 8 4 75 2
R2*8*4*100 4 8 4 100 2
R0.5*2*4*75 1 2 4 75 2
R0.75*3*4*75 1.5 3 4 75 2
R1*4*4*75 2 4 4 75 2
R1.25*5*4*75 2.5 5 4 75 2
R1.5*6*4*75 3 6 4 75 2
R2.5*10*5*50 5 10 5 50 2
R2.5*10*5*75 5 10 5 75 2
R2.5*10*5*100 5 10 5 100 2
R0.5*2*6*50 1 2 6 50 2
R0.75*3*6*50 1.5 3 6 50 2
R1*4*6*50 2 4 6 50 2
R1.25*5*6*50 2.5 5 6 50 2
R1.5*6*6*50 3 6 6 50 2
R2*8*6*50 4 8 6 50 2
R2.5*10*6*50 5 10 6 50 2
R3*12*6*50 6 12 6 50 2
R3*12*6*75 6 12 6 75 2
R3*12*6*100 6 12 6 100 2
R3*12*6*150 6 12 6 150 2
R3.5*14*8*60 7 14 8 60 2
R4*16*8*60 8 16 8 60 2
R4*16*8*75 8 16 8 75 2
R4*16*8*100 8 16 8 100 2
R4*16*8*150 8 16 8 150 2
R4.5*18*10*75 9 18 10 75 2
R5*20*10*75 10 20 10 75 2
R5*20*10*100 10 20 10 100 2
R5*20*10*150 10 20 10 150 2
R5.5*22*12*75 11 22 12 75 2
R6*24*12*75 12 24 12 75 2
R6*24*12*100 12 24 12 100 2
R6*24*12*150 12 24 12 150 2
R7*28*14*80 14 28 14 80 2
R7*28*14*100 14 28 14 100 2
R7*28*14*150 14 28 14 150 2
R8*32*16*100 16 32 16 100 2
R8*32*16*150 16 32 16 150 2
R9*36*18*100 18 36 18 100 2
R9*36*18*150 18 36 18 150 2
R10*40*20*100 20 40 20 100 2
R10*40*20*150 20 40 20 150 2




Applications:

Are you looking for a tool suitable for milling and cutting various types of steel such as carbon, malleable cast iron, alloy, and stainless steel? Look no further! Our tool is ideal for slot and hole machining in these materials.

Not only that, but our tool is also versatile and compatible with a wide range of CNC machining centers, engraving machines, and other high-speed CNC machine tools. You won't have to worry about compatibility issues, as our tool is designed to work seamlessly with your preferred equipment.





Tag:

HRC 55° Ball Nose End Mill,

2 Flutes Ball Nose End Mill,

AITiSiN Coating Ball Nose End Mill
