8mm Dia 8208*60-4F Flat End Mill TiAISiNX Square End Mill For Steel & Cast Iron

Name: 8mm Dia 8*20*8*60-4F Flat End Mill TiAISiNX Square End Mill For Steel & Cast Iron
Brand: CHENGDU BABOS CUTTING TECH CO.,LTD
SKU: 8*20*8*60-4F
Availability: InStock

Brand Name:	BABOS
Model Number:	8208*60-4F
MOQ:	10pcs
Price:	Negotiable
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:	20,000PCS per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Cut Diameter:

8mm

Cut Length:

20mm

Shank Diameter:

8mm

Overall Length:

60mm

Product Material:

Solid Tungsten Carbide

Coating/Finish Type:

TiAISiNX

Helix Angle:

35° Or Customized

Application:

Side Milling, Face Milling,End Milling

End Type:

Square Flat End

Packaging Details:

Plastic Box

Highlight:

8mm Flat End Mill

8208*60 Flat End Mill

8mm Square End Mill

Product Description

12mm Dia 124512*100L-4F Flat End Mill TiAISiNX Square End Mill For Steel & Cast Iron

Product Description:

This 8mm diameter 4-flute square end mill is designed for high-precision machining of steel and cast iron. With its durable TiAlSiNX coating, it offers excellent wear resistance, heat stability, and extended tool life. The 4-flute design ensures smooth cutting performance, making it an ideal tool for slotting, profiling, and finishing operations in CNC machining.

Specifications:

Flutes: 4
Cutting Diameter: 8mm
Cutting Length: 20mm
Shank Diameter: 8mm
Overall Length: 60mm
Helix Angle: 35° or Customized
Material: Solid Carbide
Coating: TiAlSiNX (Titanium Aluminum Silicon Nitride)
Application: Suitable for steel, cast iron, and hardened materials

8mm Dia 8*20*8*60-4F Flat End Mill TiAISiNX Square End Mill For Steel & Cast Iron 0

Product Specifications

HRC65 Carbide 4 Flutes Flat End Mill
Standard Length
Standard Length
Cut Dia (mm)	Cut Length (mm)	Shank Dia (mm)	Overall Length (mm)	Flutes	Helix Angle
D	Lc	d	L	Flutes	Helix Angle
3	8	3	50	4	35°
1	3	4	50	4	35°
1.5	4	4	50	4	35°
2	6	4	50	4	35°
2.5	7	4	50	4	35°
3	8	4	50	4	35°
4	10	4	50	4	35°
5	13	5	50	4	35°
5	13	6	50	4	35°
6	15	6	50	4	35°
7	18	8	60	4	35°
8	20	8	60	4	35°
10	25	10	75	4	35°
12	30	12	75	4	35°
14	35	14	80	4	35°
14	45	14	100	4	35°
16	45	16	100	4	35°
18	45	18	100	4	35°
20	45	20	100	4	35°
Extended Length
Cut Dia (mm)	Cut Length (mm)	Shank Dia (mm)	Overall Length (mm)	Flutes	Helix Angle
D	Lc	d	L	Flutes	Helix Angle
4	16	4	75	4	35°
4	20	4	100	4	35°
5	20	5	75	4	35°
5	25	5	100	4	35°
6	20	6	75	4	35°
6	30	6	100	4	35°
6	40	6	150	4	35°
8	25	8	75	4	35°
8	35	8	100	4	35°
8	50	8	150	4	35°
10	40	10	100	4	35°
10	50	10	150	4	35°
12	45	12	100	4	35°
12	55	12	150	4	35°
14	60	14	150	4	35°
16	60	16	150	4	35°
18	60	18	150	4	35°
20	70	20	150	4	35°

Key Features:

✅ 35° Helix Angle – Reduces cutting resistance and improves surface finish.
✅ 4-Flute Design – Enhances stability and allows for efficient material removal.
✅ TiAlSiNX Coating – Provides superior hardness, oxidation resistance, and extended tool life.
✅ Solid Carbide Construction – Ensures high rigidity, strength, and durability.
✅ Square End Geometry – Perfect for slotting, profiling, contouring, and finishing.
✅ Precision Ground – Offers excellent accuracy and performance for CNC machining.

Recommended for CNC machining in automotive, aerospace, mold-making, and general industrial applications.
