75mm Overall Length HRC 65 R12*30*12 Dia TiAISiN Coated 2 Flutes Carbide Ball Nose End Mill Cutter with Customization Option

All Products
Tungsten Carbide Burr (96)
Annular Cutter (28)
Milling Cutter (61)
Circular Saw (4)
Screw Tap (9)
Drill Bit (17)
China CHENGDU BABOS CUTTING TECH CO.,LTD certification
China CHENGDU BABOS CUTTING TECH CO.,LTD certification
I'm Online Chat Now

75mm Overall Length HRC 65 R12*30*12 Dia TiAISiN Coated 2 Flutes Carbide Ball Nose End Mill Cutter with Customization Option

75mm Overall Length HRC 65 R12*30*12 Dia TiAISiN Coated 2 Flutes Carbide Ball Nose End Mill Cutter with Customization Option
75mm Overall Length HRC 65 R12*30*12 Dia TiAISiN Coated 2 Flutes Carbide Ball Nose End Mill Cutter with Customization Option
video play

Large Image :  75mm Overall Length HRC 65 R12*30*12 Dia TiAISiN Coated 2 Flutes Carbide Ball Nose End Mill Cutter with Customization Option

Product Details:
Place of Origin: China
Brand Name: BABOS
Model Number: R12*30*12*75 2T
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: Negotiable
Packaging Details: Plastic Box
Delivery Time: 3 days for standard products, 1-2weeks for custom products.
Payment Terms: L/C,D/A,D/P,T/T,Western Union
Supply Ability: 20,000PCS per month
Contact Now
Detailed Product Description
Cut Diameter: 12mm Shank Diameter: 30mm
Overall Length: 75mm Coating/Finish Type: TiAISiN
Machine Type: Finish Machining, Roughing Machining Application: Milling And Cutting Of Carbon Steel, Malleable Cast Iron, Alloy Steel, Stainless Steel, Etc.
Tolerance: 0.020mm~0.050mm Customize: Available
Highlight:

75mm Carbide Ball Nose End Mill

,

Carbide Ball Nose End Mill Cutter

HRC 65 R12*24*12*75 Dia TiAISiN Coated 2 Flutes Carbide Ball Nose End Mill Cutter

Product Description:

The HRC65 R12 2-Flute Carbide Ball Nose End Mill Cutter is a high-precision tool designed for 3D contouring, deep cavity milling, and finishing operations on hardened materials. With an ultra-hard TiAlSiN (Titanium Aluminum Silicon Nitride) coating, this end mill offers superior heat resistance, wear resistance, and extended tool life, making it ideal for cutting hardened steels up to HRC65, alloy steels, tool steels, and cast iron.

The ball nose geometry ensures smooth surface finishes and accurate profiling, while the 2-flute design allows for efficient chip evacuation, especially in deep pocket and high-speed machining applications.

Specifications:

Parameter Details
Hardness HRC65
Cutting Diameter 12mm
Flute Length 30mm
Shank Diameter 12mm
Overall Length 75mm
Number of Flutes 2 Flutes
End Type Ball Nose End
Material Ultra-Fine Solid Carbide
Coating TiAlSiN (Titanium Aluminum Silicon Nitride)
 75mm Overall Length HRC 65 R12*30*12 Dia TiAISiN Coated 2 Flutes Carbide Ball Nose End Mill Cutter with Customization Option 0
HRC 2 Flutes Ball Nose End Mill Specifications
(For Carbon Steel, Alloy Steel, Stainless Steel, Cast Iron)
Sizes Cut Diameter
D		 Cut Length
Lc		 Shank Diameter
d		 Overall Length
L		 Flutes No.
R1.5*6*3*50 3 6 3 50 2
R1.5*6*3*75 3 6 3 75 2
R1.5*6*3*100 3 6 3 100 2
R0.5*2*4*50 1 2 4 50 2
R0.75*3*4*50 1.5 3 4 50 2
R1*4*4*50 2 4 4 50 2
R1.25*5*4*50 2.5 5 4 50 2
R1.5*6*4*50 3 6 4 50 2
R1.75*7*4*50 3.5 7 4 50 2
R2*8*4*50 4 8 4 50 2
R2*8*4*75 4 8 4 75 2
R2*8*4*100 4 8 4 100 2
R0.5*2*4*75 1 2 4 75 2
R0.75*3*4*75 1.5 3 4 75 2
R1*4*4*75 2 4 4 75 2
R1.25*5*4*75 2.5 5 4 75 2
R1.5*6*4*75 3 6 4 75 2
R2.5*10*5*50 5 10 5 50 2
R2.5*10*5*75 5 10 5 75 2
R2.5*10*5*100 5 10 5 100 2
R0.5*2*6*50 1 2 6 50 2
R0.75*3*6*50 1.5 3 6 50 2
R1*4*6*50 2 4 6 50 2
R1.25*5*6*50 2.5 5 6 50 2
R1.5*6*6*50 3 6 6 50 2
R2*8*6*50 4 8 6 50 2
R2.5*10*6*50 5 10 6 50 2
R3*12*6*50 6 12 6 50 2
R3*12*6*75 6 12 6 75 2
R3*12*6*100 6 12 6 100 2
R3*12*6*150 6 12 6 150 2
R3.5*14*8*60 7 14 8 60 2
R4*16*8*60 8 16 8 60 2
R4*16*8*75 8 16 8 75 2
R4*16*8*100 8 16 8 100 2
R4*16*8*150 8 16 8 150 2
R4.5*18*10*75 9 18 10 75 2
R5*20*10*75 10 20 10 75 2
R5*20*10*100 10 20 10 100 2
R5*20*10*150 10 20 10 150 2
R5.5*22*12*75 11 22 12 75 2
R6*24*12*75 12 30 12 75 2
R6*24*12*100 12 45 12 100 2
R6*24*12*150 12 55 12 150 2
R7*28*14*80 14 35 14 80 2
R7*28*14*100 14 40 14 100 2
R7*28*14*150 14 60 14 150 2
R8*32*16*100 16 32 16 100 2
R8*32*16*150 16 32 16 150 2
R9*36*18*100 18 36 18 100 2
R9*36*18*150 18 36 18 150 2
R10*40*20*100 20 40 20 100 2
R10*40*20*150 20 40 20 150 2


Flute Number 2
Coating/Finish Type TiAISiN
Helix Angle 30 Degrees
Application Internal Part Radius Cutting
Tolerance -0.010mm~-0.030mm
Machine Type Finish Machining, Roughing Machining
Customize Available
OEM Available
Sample Order Accepted
