8pcs Tungsten Carbide Burr Set Deburring Shaping Tungsten Carbide Burr 1 4 Shank

8pcs Tungsten Carbide Burr Set Deburring Shaping Tungsten Carbide Burr 1 4 Shank

Brand Name: BABOS
Model Number: BBS-1 8pcs Set
MOQ: 20pcs
Price: Negotiable
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 10,0000pcs per month
Detail Information
Place of Origin:
China
Material:
Tungsten Carbide
Shape:
SF-5,SF-3,SD-1,SD-3,SC-1,SC-3,SA-3,SA-5
Shank Diameter:
1/4 Inch
Flute Type:
Standard Double Cut
Suitable For:
Machining Surface Profile Of Workpiece
Application:
Deburring, Shaping, And Finishing
Package Quantity:
1
Max Rpm:
50,000
Packaging Details:
Plastic Box
Highlight:

8pcs Carbide Burr Set

,

tungsten carbide burr set Deburring

,

Shaping tungsten carbide burr 1 4 shank

Product Description

BBS-1 8pcs Tungsten Carbide Burrs Set With Standard Double Cut 1/4”Shank Diameter


Description:

This 8-piece set of double cut carbide burrs include various burr shapes with a 6mm cutting diameter and a 6mm shank diameter. This burr set including: SF-5,SF-3,SD-1,SD-3,SC-1,SC-3,SA-3,SA-5. These 8 carbide burrs are the preferred choice for precise metal removal when shaping, leveling, or porting cast iron, steel and other ferrous metals.


BBS-1 8pcs Tungsten Carbide Burrs Set

Brand: BABOS

Name: BBS-1 8 Pcs Tungsten Carbide Burr Set
Cutting Head Material: Tungsten Carbide YG7/YG10X

Hardness: 90.5-92HRC
Shank Material: 40Cr Steel
Contain Type: SF-5,SF-3,SD-1,SD-3,SC-1,SC-3,SA-3,SA-5

Cut Dia: 1/4'', 3/8'', 1/2''
Shank Diameter: 1/4"
Cut Type: STANDARD CUT(M), STANDARD DOUBLE CUT (X), WIDE CUT (C), FINE CUT (F), ALUMINUM CUT (W), DIAMOND CUT(D)
Carbide Burr Set: PE-HD slap-up plastic box x1, carbide burrs x8.

Burr Set Advantages: 8pcs carbide burr set are complete in types, which basically meet the polishing requirements of each process of the general workpiece, and it is easier to take and keep.





Detailed Product Parameter About BBS-1 8pcs Tungsten Carbide Burr Set


8pcs Tungsten Carbide Burrs Set
Shank Dia. (inch) Cutter Dia. (inch) Length of Cut (inch) Overall Length (inch) Tool No.
1/4'' 3/8" 3/4'' 2-1/2" SA-3
1/4'' 1/2'' 1'' 2-3/4" SA-5
1/4'' 1/4" 5/8" 2'' SC-1
1/4'' 3/8" 3/4'' 2-1/2" SC-3
1/4'' 1/4" 7/32" 2'' SD-1
1/4'' 3/8" 5/16" 2-1/16" SD-3
1/4'' 3/8'' 3/4'' 1/2'' SF-3
1/4'' 1/2'' 1'' 3/4'' SF-5





Customization:

  1. Various packing solutions of carbide burr set are available.
  2. Please contact us if you need more information about burr sets with any shape.
  3. OEM is avaliable.
  4. Free sample is avaliable.


Cut Selection Guide:


STANDARD CUT(M)

STANDARD DOUBLE

CUT (X)

WIDE CUT (C)

FINE CUT

(F)

ALUMINUM

CUT(W)

DIAMOND CUT(D)
