8mm Dia R4*8*16*8*100L 2Flutes TiAISiN Carbide Ball Nose End Mill For Carbon Steel Alloy Steel Cast Iron

All Products
Tungsten Carbide Burr (96)
Annular Cutter (28)
Milling Cutter (61)
Circular Saw (4)
Screw Tap (9)
Drill Bit (17)
China CHENGDU BABOS CUTTING TECH CO.,LTD certification
China CHENGDU BABOS CUTTING TECH CO.,LTD certification
I'm Online Chat Now

8mm Dia R4*8*16*8*100L 2Flutes TiAISiN Carbide Ball Nose End Mill For Carbon Steel Alloy Steel Cast Iron

8mm Dia R4*8*16*8*100L 2Flutes TiAISiN Carbide Ball Nose End Mill For Carbon Steel Alloy Steel Cast Iron
8mm Dia R4*8*16*8*100L 2Flutes TiAISiN Carbide Ball Nose End Mill For Carbon Steel Alloy Steel Cast Iron
video play

Large Image :  8mm Dia R4*8*16*8*100L 2Flutes TiAISiN Carbide Ball Nose End Mill For Carbon Steel Alloy Steel Cast Iron

Product Details:
Place of Origin: China
Brand Name: BABOS
Model Number: R4*8*16*8*100L-2F
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: Negotiable
Packaging Details: Plastic Box
Delivery Time: 3 days for standard products, 1-2weeks for custom products.
Payment Terms: L/C,D/A,D/P,T/T,Western Union
Supply Ability: 20,000PCS per month
Contact Now
Detailed Product Description
Cut Diameter: 8mm Cut Length: 16mm
Shank Diameter: 8mm Overall Length: 100mm
Coating/Finish Type: TiAISiN Machine Type: Finish Machining, Roughing Machining
Application: Milling And Cutting Of Carbon Steel, Malleable Cast Iron, Alloy Steel, Stainless Steel, Etc. Tolerance: -0.015mm~-0.040mm
Customize: Available
Highlight:

R4*8*16*8*100L Carbide Ball Nose End Mill

,

2Flutes Carbide Ball Nose End Mill

,

8mm Carbide Ball Nose End Mill

8mm Dia R4*8*16*8*100L 2Flutes TiAISiN Carbide Ball Nose End Mill For Carbon Steel Alloy Steel Cast Iron

Product Description:

This 8mm Ball Nose End Mill is engineered for precision 3D contouring, slotting, and surface finishing across tough materials such as carbon steel, alloy steel, and cast iron. With its 2-flute ball nose geometry and premium TiAlSiN (Titanium Aluminum Silicon Nitride) coating, this tool offers excellent durability and performance in demanding machining applications.



Specifications:

  • Cutting Diameter (Ball Nose): 8mm (R4 radius)
  • Flute Length: 8mm
  • Cutting Length: 16mm
  • Shank Diameter: 8mm
  • Overall Length: 100mm
  • Flutes: 2



Coating:

The TiAlSiN coating provides enhanced wear resistance, oxidation protection, and thermal stability, making it ideal for high-speed machining and dry cutting conditions.

Features:

  • Ultra-fine carbide substrate for high toughness and rigidity
  • TiAlSiN coating for outstanding performance in high-heat and high-load environments
  • Ball nose geometry for accurate 3D profiling and excellent surface finishes
  • 2-flute design ensures smooth chip evacuation and reduced cutting forces

Applications:

  • Carbon Steel
  • Alloy Steel
  • Cast Iron

Perfect for mold & die industries, aerospace components, automotive parts, and general-purpose milling of medium to hard materials.



8mm Dia R4*8*16*8*100L 2Flutes TiAISiN Carbide Ball Nose End Mill For Carbon Steel Alloy Steel Cast Iron 0


2 Flutes Ball Nose End Mill Specifications
(For Carbon Steel, Alloy Steel, Cast Iron)
Sizes Cut Diameter
D		 Cut Length
Lc		 Shank Diameter
d		 Overall Length
L		 Flutes No.
R1.5*6*3*50 3 6 3 50 2
R1.5*6*3*75 3 6 3 75 2
R1.5*6*3*100 3 6 3 100 2
R0.5*2*4*50 1 2 4 50 2
R0.75*3*4*50 1.5 3 4 50 2
R1*4*4*50 2 4 4 50 2
R1.25*5*4*50 2.5 5 4 50 2
R1.5*6*4*50 3 6 4 50 2
R1.75*7*4*50 3.5 7 4 50 2
R2*8*4*50 4 8 4 50 2
R2*8*4*75 4 8 4 75 2
R2*8*4*100 4 8 4 100 2
R0.5*2*4*75 1 2 4 75 2
R0.75*3*4*75 1.5 3 4 75 2
R1*4*4*75 2 4 4 75 2
R1.25*5*4*75 2.5 5 4 75 2
R1.5*6*4*75 3 6 4 75 2
R2.5*10*5*50 5 10 5 50 2
R2.5*10*5*75 5 10 5 75 2
R2.5*10*5*100 5 10 5 100 2
R0.5*2*6*50 1 2 6 50 2
R0.75*3*6*50 1.5 3 6 50 2
R1*4*6*50 2 4 6 50 2
R1.25*5*6*50 2.5 5 6 50 2
R1.5*6*6*50 3 6 6 50 2
R2*8*6*50 4 8 6 50 2
R2.5*10*6*50 5 10 6 50 2
R3*12*6*50 6 12 6 50 2
R3*12*6*75 6 12 6 75 2
R3*12*6*100 6 12 6 100 2
R3*12*6*150 6 12 6 150 2
R3.5*14*8*60 7 14 8 60 2
R4*16*8*60 8 16 8 60 2
R4*16*8*75 8 16 8 75 2
R4*16*8*100 8 16 8 100 2
R4*16*8*150 8 16 8 150 2
R4.5*18*10*75 9 18 10 75 2
R5*20*10*75 10 20 10 75 2
R5*20*10*100 10 20 10 100 2
R5*20*10*150 10 20 10 150 2
R5.5*22*12*75 11 22 12 75 2
R6*24*12*75 12 24 12 75 2
R6*24*12*100 12 24 12 100 2
R6*24*12*150 12 24 12 150 2
R7*28*14*80 14 28 14 80 2
R7*28*14*100 14 28 14 100 2
R7*28*14*150 14 28 14 150 2
R8*32*16*100 16 32 16 100 2
R8*32*16*150 16 32 16 150 2
R9*36*18*100 18 36 18 100 2
R9*36*18*150 18 36 18 150 2
R10*40*20*100 20 40 20 100 2
R10*40*20*150 20 40 20 150 2
